ALL PACKED IN 6 FT (1.82 M) LONG BOX | NET 45 LBS (20.41 KGS)
Select one of the following links to view the Table in decimals,
fractions of an inch, or in millimeters:
|
|
|
|
|
|
|
|
|
| PROFILE | A-CHANNEL | B-FACE | C-WIDTH | D-DEPTH | E-RADIUS | STRIPS/ 45 LB BOX | STRIPS/ 40 LB BOX |
|
|
|
|
|
|
|
|
|
| RU-80 | 3.9624 | 5.1308 | 5.08 | 3.048 | 3.0734 | 65 | 58 |
| RU-81 | 3.9624 | 5.1308 | 5.7912 | 3.0226 | 2.921 | 61 | 54 |
| RU-85 | 5.08 | 5.9182 | 6.858 | 3.8862 | 6.7818 | 58 | 52 |
| RU-87 | 3.9116 | 4.5212 | 5.4356 | 2.4892 | 2.8448 | 84 | 75 |
| All dimensions in millimeters |
|
|
|
|
|
|
|
|
|
|
| PROFILE | A-CHANNEL | B-FACE | C-WIDTH | D-DEPTH | E-RADIUS | STRIPS/ 45 LB BOX | STRIPS/ 40 LB BOX |
|
|
|
|
|
|
|
|
|
| SU-25 | 3.9624 | 6.3754 | 6.35 | 3.0226 | - | 43 | 38 |
| SU-38 | 3.9624 | 10.0076 | 6.35 | 3.0226 | - | 20 | 18 |
| SU-53 | 3.5814 | 5.5626 | 5.1816 | 3.9624 | - | 68 | 60 |
| SU-54 | 3.9624 | 4.7498 | 6.0198 | 3.81 | - | 71 | 63 |
| SU-55 | 3.9878 | 6.0198 | 6.1468 | 4.826 | - | 58 | 52 |
| SU-56 | 3.4544 | 1.905 | 4.9784 | 1.0668 | - | 170 | 151 |
| SU-57 | 3.556 | 2.5654 | 5.715 | 1.4478 | - | 103 | 92 |
| SU-57N | 3.1496 | 2.5908 | 5.715 | 1.4478 | - | 98 | 87 |
| SU-58 | 3.5052 | 2.3622 | 5.6134 | 1.27 | 106 | 94 | |
| SU-58N | 3.048 | 2.3622 | 5.6134 | 1.27 | - | 101 | 90 |
| SU-59 | 4.1148 | 2.0066 | 5.8166 | 1.4224 | - | 171 | 152 |
| SU-60 | 3.9624 | 5.588 | 5.588 | 4.7752 | - | 83 | 74 |
| All dimensions in millimeters |
|
|
|
|
|
|
|
|
|
|
| PROFILE | A-CHANNEL | B-FACE | C-WIDTH | D-DEPTH | E-RADIUS | STRIPS/ 45 LB BOX | STRIPS/ 40 LB BOX |
|
|
|
|
|
|
|
|
|
| RU-01 | 3.96 | 2.2098 | 5.1308 | 1.4986 | 1.2192 | 195 | 173 |
| RU-61 | 3.9624 | 2.3876 | 6.35 | 14.224 | 1.3716 | 120 | 107 |
| RU-62 | 5.588 | 5.2324 | 8.3312 | 3.683 | 4.318 | 63 | - |
| RU-70 | 3.9624 | 4.8006 | 6.35 | 3.5306 | 3.3528 | 73 | 65 |
| RU-71 | 4.7752 | 6.35 | 7.8232 | 4.4704 | 7.3406 | 43 | 38 |
| RU-72 | 4.445 | 5.1308 | 7.239 | 4.064 | 5.4102 | 42 | 37 |
| RU-83A | 2.794 | 3.3528 | 4.4196 | 1.8034 | 142 | 126 | |
| RU-84 | 3.7592 | 4.4196 | 6.5532 | 2.9972 | 3.6576 | 77 | 68 |
| RU-86 | 3.9624 | 4.8006 | 6.35 | 3.0226 | 4.5212 | 48 | 43 |
| RU-90 | 3.302 | 3.175 | 5.8674 | 2.3114 | 4.318 | 106 | 94 |
| RU-92 | 3.9624 | 2.6924 | 5.7404 | 1.143 | 2.54 | 99 | 88 |
| RU-93 | 3.9624 | 3.5306 | 5.9944 | 2.0066 | 2.5908 | 85 | 76 |
| RU-94 | 3.4544 | 2.3876 | 5.6642 | 1.3462 | 1.3208 | 134 | 119 |
| RU-95 | 2.7686 | 3.302 | 5.1054 | 1.7018 | 1.8034 | 105 | 93 |
| RU-98 | 3.556 | 1.8796 | 6.1976 | 1.1684 | 1.2192 | 167 | 148 |
| RU-98R | 3.556 | 2.7432 | 5.842 | 1.3208 | 1.3716 | 116 | 103 |
| RU-100 | 3.9624 | 1.905 | 5.7912 | 1.1684 | 0.9652 | 162 | 144 |
| RU-100S | 3.9624 | 2.6924 | 6.1468 | 1117.6 | 13.716 | 98 | 87 |
| RU-102 | 3.8862 | 2.54 | 5.842 | 1.524 | 1.3462 | 127 | 113 |
| RU-105 | 3.2258 | 2.4892 | 5.3594 | 1.7018 | 7.874 | 190 | 169 |
| RU107 | 3.8354 | 4.445 | 5.8674 | 2.1082 | 21.336 | 86 | 76 |
| RU-108 | 4.318 | 3.5306 | 6.858 | 2.5146 | 6.2484 | 91 | 81 |
| All dimensions in millimeters |
|
|
|
|
|
|
|
|
|
|
| PROFILE | A-CHANNEL | B-FACE | C-WIDTH | D-DEPTH | E-RADIUS | STRIPS/ 45 LB BOX | STRIPS/ 40 LB BOX |
|
|
|
|
|
|
|
|
|
| RU-75 | 3.429 | 2.6416 | 5.8928 | 1.4224 | - | 104 | 92 |
| RU96 | 4.826 | 3.048 | 6.1976 | 2.032 | - | 124 | 110 |
| RU-96W | 5.334 | 3.048 | 6.7056 | 2.032 | - | 93 | 83 |
| RU-97W | 6.985 | 3.048 | 8.3566 | 2.032 | - | 89 | 79 |
| RU-104 | 7.112 | 3.175 | 9.4488 | 2.413 | - | 66 | 59 |
| RU-109 | 4.5212 | 3.5052 | 6.5024 | 2.4892 | - | 88 | 78 |
| All dimensions in millimeters |
|
